Load Cell Categories

Below is a list of our load cells sorted by category.

Metrology Grade Force Transducers

Calibration Standard
300 - 100K lbf
1.5 - 500 kN

Calibration Standard High Capacity
300 - 100K lbf
1.5 - 500 kN

General Purpose Load Cells

Shear Web
300-100K lbf
1.5-500 kN

2202 Rod End
5K-25K lbf

2206 Rod End
25K lbf

Shear Web High Capacity
200K-1000K lbf
1000-4500 kN

Shear Web Compression Only
300-200K lbf
1.5-1000 kN

Precision Shear Web Load Cells

Precision Shear Web
300-100K lbf
1.5-500 kN

Precision Shear Web High Capacity
200K-1000K lbf
1000-4500 kN

Fatigue Rated Load Cells

Fatigue Rated Low Capacity
25-300 lbf
125-1500 N

Fatigue Rated Shear Web
150-50K lbf
0.75-250 kN

High Capacity Fatigue Rated
100K-500K lbf
500-2250 kN

Multi-Axis Load Cells

Axial Force and Torque
300/500 lbf/lbf-in
10K/3Klbf/lbf-in

Axial Force and Moment
500-50K lbf
100K/50K lbf

Column Type Load Cells

5200 Universal Column
High Capacity
100K-1000K lbf

5100 Compression Column
High Capacity
100K-1000K lbf

5000 Universal Column
High Capacity
100K-1000K lbf

Harsh Enviroment Load Cells

Stainless Steel Shear Web
5K-100K lbf
25-500 kN

Fatigue Stainless Steel Shear Web
2.5K-25K lbf
12.5-125 kN

Low Height Column
500-7.5K lbf

Compact Stainless Steel Compression
10K, 25K lbf
45, 100 kN

Low Height Stainless Steel
500-5K lbf

General Purpose Stainless Steel
10K-20K lbf

Miniature Load Cells

Premium S-Type
500-5K lbf

Overload Protected S-Type
2.2-225 lbf
10-1000 N

Low Height S-Beam
10-1K lbf

Load Washer
2K-10K lbf
45, 100 kN

Reaction Torque Load Cells

Miniature Reaction Torque
25-500 lbf-in

Load Cell Accessories

• Calibration Adapters
• Thread Adapters
• Couplers
• Jam Nuts
• Load Buttons
• Compression Plate
• Instrument Cables
• Mating Connectors
